What is LDA electric single beam crane?
Engineered for precision and durability, the LDA Electric Single-Girder Crane integrates a robust main girder formed from welded steel plates and I-beams, complemented by end girders, an electric hoist, and a smooth-operating traveling mechanism. The hoist moves seamlessly along the girder’s lower flange, enabling efficient and stable load handling. Designed with a lightweight structure, this crane ensures straightforward installation and minimal maintenance.
It offers flexible operation through two control methods: ground control or an operator cabin (available in open or enclosed configurations), which can be positioned on the left or right side as needed. Entry options include side or end access, providing adaptability to diverse workspace layouts.
Features of Electric Single Beam Crane
Key Advantages
Material: High-strength Q235 steel
Frame: Integrated, rigid steel box design
Surface Treatment: Sandblasted for rust resistance
Travel Motor: Kuangyuan soft-start motor (customizable)
Main Beam: Advanced single-piece box construction, eliminating welds
Wheels: Vacuum-cast with intermediate frequency quenching
Electrical Components: Premium Schneider brand for reliability
Safety Systems
Overload weight protection
Polyurethane shock-absorbing buffers
Travel and cross-travel limit switches
Lifting height limiter
Low-voltage protection
Emergency stop mechanism
Current overload protection
Technical Parameters of Electric Single Beam Crane
Custom Solutions
We tailor cranes to match your specific requirements. For a personalized design, please share the following:
Lifting capacity
Span length
Lifting height (hook center to ground)
Voltage and power supply details
Rail requirements and travel distance
Working environment (material handled, temperature, etc.)
Plant layout or drawings (if available)
After-Sales Support
Warranty: All cranes come with a one-year quality guarantee. Defects resulting from proper operation will be addressed with complimentary replacement parts.
Post-Warranty: After the guarantee period, components are provided at cost price to ensure long-term crane performance.
