Introduction of Straddle Carrier
Straddle carriers utilize a hydraulic system to lift and stack containers up to 2–3 high. They are well-suited for mid-sized terminals, capable of performing multiple functions—transporting containers, stacking them, and loading trucks or rail cars efficiently.
Three primary configurations are available:
Platform-free with integrated lifting/transport structure – the most compact and widely used type, offering easy turning and effective stacking. Its lightweight upper frame enhances operational stability.
Platform-equipped with shared lifting/transport structure
Platform-equipped with separate lifting/transport structure
Features of Straddle Carrier
Trends: Increased Capacity & Stacking Height
To accommodate larger containers, modern straddle carriers now handle loads of 40–50 tons, a significant increase from the earlier 30–35 tons. While most units stack up to 3 layers, 4-high stacking models are becoming more common—increasing storage density by up to 50%.
Smart & Green Innovations
Unmanned Carriers: Utilize UWB + IMU positioning, 3D SLAM navigation, and LiDAR obstacle detection. Achieve trajectory errors below 10 cm and container alignment within 3 cm, significantly reducing labor costs.
Hybrid & Hydrogen Models: Cut emissions by 99% and lower fuel consumption by 50%, with zero-carbon hydrogen fuel cell options now available.
Safety & Maintenance: Equipped with blind-spot monitoring and automated data collection to reduce maintenance expenses.
Why Choose Our Straddle Carrier?
Robust Build: Welding-free U-frame beams ensure long-term structural strength.
Intelligent Control: Integrated Siemens/Schneider PLC systems with real-time fault monitoring.
Customizable: Configurable for 20 ft, 40 ft, and 45 ft containers.
Operator-Friendly: Cabin with 360° visibility and four steering modes for flexible operation.
Port Efficiency: Faster container handling than traditional cranes while optimizing yard space.
Technical Parameters of Straddle Carrier
Key Specifications
Lifting Capacity: 5–50 tons
Lifting Speed: 5–12 m/min
Power System: Electric/Hydraulic (IP54 rated)
